OMP Hobby 60" Edge 540 V2 ARF - red 1,52m
- Secure payment by card
- E-mail us, we reply swiftly!
- Fast Deliveries
- Open at shop and on phone between 16-20 Weekdays and 11-15 (OBSERVE New time) Weekends * call +46 (0) 303-776303
- Click on "Chat with us" and we can help you immediately!
* We can be busy, call again if we don´t answer!
- BrandOMP
- Operating mode:Electrical
- Delivered as:Almost-Ready-To-Fly
- Suitable for:Experienced
- Plane type:Aerobatic
- Span:1525 mm
- Length:1500 mm
- Weight:2800 g
- Wing Area:42.4 dm²
- Material:Composite
- ESC:Not Included
- Transmitter:Not Included
- Motor:Not Included
- Motor Type:Brushless
- Aileron:Yes
- Battery:Not Included
- Charger:Not Included
- BrandOMP
Description
Article no.: OMPP013R
A new version of a semi scale model of the American aerobatic aeroplane for 1,200-1,600 W brushless electric motor for experienced pilots capable of the classic pattern as well as extreme 3D style. All new is the undercarriage mount, horizontal tailplane and there is a bunch of upgrades making the assembly before flight as well the disassembly after flight much easier and quicker.
The fuselage is of - now classic - ultra light design featuring balsa and plywood Kevlar®/carbon composite reinforced parts, detachable fibreglass cowl and large fuselage/canopy hatch allowing perfect access to the entire power system and RC gear. The engine or motor is to be fitted to a plywood/composite reinforced box using a radial mount.
The two-piece all-balsa wing with a symmetrical airfoil uses a carbon tube joiner; the wing halves are secured with screws to the fuselage. The large ailerons are controlled by a single servo each. You can install the supplied SFG winglets to the wing tips.
The empennage is a light all-balsa work; the horizontal tailplane is a single-piece, glued into the fuselage. The elevator and rudder are controlled by servos installed in the tail part of the fuselage.
The entire model is covered by the ULTRACOTE® iron-on film (ULTRACOTE® is the trade mark for the ORACOVER® film used in the USA.)
The main undercarriage features carbon composite legs, fibreglass spats and lightweight wheels; the tail wheel with a carbon bracket is coupled with the rudder.
You will need 1,200-1,1600 W brushless electric motor (e.g. KAVAN PRO 5050-515), 80-100 A ESC and 40C 3,300-4,000 mAh 6S LiPo pack.
You will need at least 4-channel RC set to control your Edge 540 but 6-channel computer radio i preferred - the precise set-up of servos, optimized dual and exponential rates is the must for aerobatic flying - the pattern as well as extreme 3D.
You will need 4 fast and strong digital mini servos, like KAVAN GO-1035MG Plus.
The ARTF kit contents: Oracover® covered fuselage, wing and tailplane, painted fibreglass cowl, carbon undercarriage, tail wheel assembly, wheels, set of accessories and instruction manual.
